Parent Layer: Manizales

Name: T52_MAPA_ESTRATÉGICO_DE_RUIDO_SECTOR_3_MILAN_TRÁFICO_NOCHE

Display Field: ISOVALUE

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><P><SPAN STYLE="font-size:16pt"><SPAN>Para la obtención del mapa de ruido del periodo nocturno debido al tráfico, en el sector Milán, se utilizó el mé</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>todo de </SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>cá</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>lculo </SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>Cnossos-EU, propuesto por la Directiva Europea 2015/996 como mé</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>t</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>odo comú</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>n</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN> de evaluación. Este mé</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>todo </SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>establece la emisión y la propagació</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>n </SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>del trá</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>fico en bandas de octava</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>. Como datos de entrada para el método de cálculo se usaron aforos provenientes de datos abiertos de la secretaria de movilidad y se completó</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN> con tra</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>bajo en campo para establecer velocidades de paso y datos de aforo faltantes. Se usó</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN> Soundplan 8.1 para calcular los niveles de ruido en una grilla de 10m x 10m a 4m de altura en los diferentes sectores. El mapa se realiza en el marco del contrato de consu</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>ltorí</SPAN></SPAN><SPAN STYLE="font-size:16pt"><SPAN>a 179-2018.</SPAN></SPAN></P></DIV></DIV>

Service Item Id: edfe859c66b94caeb31b3774bd4d77bd

Copyright Text: Corporación regional autónoma de caldas -CORPOCALDAS, AAC centro de acústica aplicada Colombia.

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 844298.3953
YMin: 1049401.5702
XMax: 845265.9862000002
YMax: 1050109.9465999994
Spatial Reference: 21892  (21897)

Drawing Info:

Renderer:
Class Breaks Renderer:
Field: ISOVALUE
Min. Value: 0.0
ClassBreakInfos:
• Class Maximum Value: 0
  Label: 0,000000
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [245, 245, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 50
  Label: 0,000001 - 50,000000
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [245, 184, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 60
  Label: 50,000001 - 60,000000
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [245, 122, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 70
  Label: 60,000001 - 70,000000
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [245, 61, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 80
  Label: 70,000001 - 80,000000
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [245, 0, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ISOVALUE ( type: esriFieldTypeSingle, alias: ISOVALUE )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• GEODBID ( type: esriFieldTypeString, alias: GEODBID, length: 15 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
